BAND-IT 316 Stainless Steel Clip
BAND-IT 316 Stainless Steel Clip
Reliable 316 Stainless Steel Fastening for Demanding Industrial Applications
The BAND-IT® 316 Stainless Steel Clip is a durable fastening component designed for use with 316 stainless steel banding, providing excellent corrosion resistance and dependable performance in demanding environments.
- It is particularly suitable for applications exposed to moisture, salt spray, marine conditions and corrosive elements.
- Supplied by Arabian Arrow Supply & Services Company Limited (ARACO) in Saudi Arabia, the BAND-IT® 316 SS Clip is suitable for industrial, marine, electrical, construction, cable management and general banding applications where reliable stainless steel fastening is required.
- Designed to accommodate single- or double-wrapped band configurations, the clip allows band clamps to be formed around different contours and shapes, making it a versatile solution for securing cables, pipes, hoses and other components.
316 Stainless Steel Clip
| Part No. | Material | Width (mm) | Package Quantity | Weight (Kg) |
|---|---|---|---|---|
| AE4529 | 316 SS | 6.4 | 100/Box | 0.1 |
| AE4539 | 316 SS | 9.6 | 100/Box | 0.3 |
| AE4549 | 316 SS | 12.7 | 100/Box | 0.4 |
| AE4559 | 316 SS | 15.8 | 100/Box | 0.5 |
| AE4569 | 316 SS | 19.1 | 100/Box | 0.6 |
Key Features of 316 Stainless Steel Clip
316 Stainless Steel Construction
Provides excellent corrosion resistance for demanding industrial and outdoor environments.
Marine-Grade Performance
Suitable for general banding applications, including marine splash-zone environments.
Single or Double Wrap
Supports both single- and double-wrapped band configurations.
Versatile Banding
Allows clamps to be formed around various contours and shapes.
Coated & Uncoated Compatibility
Designed for use with both coated and uncoated 316 stainless steel banding.
Multiple Width Options
Available to suit different BAND-IT® 316 stainless steel band widths.
Technical Specifications of 316 Stainless Steel Clip
| Specification | Details |
|---|---|
| Material | 316 Stainless Steel |
| Clip Width | 3/4 in (19.1 mm) |
| Package Quantity | 100 Clips/Box |
| Compatible Banding | 316 Stainless Steel Banding |
| Band Configuration | Single or Double Wrap |
| Application | Banding & Clamping |
| Corrosion Resistance | Excellent |
316 Stainless Steel Clip Applications and uses
Marine & Coastal Installations
Securing cables, hoses, and rigging on boats, ships, docks, and offshore oil platforms.
Mounting marine equipment and underwater hardware exposed to constant saltwater.
Utility & Municipal Poles
Mounting traffic signs, streetlights, security cameras, and electrical boxes to wooden, concrete, or metal utility poles.
Securing aerial fiber optic cables and power lines.
Industrial & Petrochemical Plants
Fastening thermal insulation jackets around high-temperature steam pipes, boilers, and exhaust systems.
Securing heavy-duty industrial hoses in chemical processing plants.
Telecommunications & Electronics
Bundling exterior wiring and coaxial cables that must withstand harsh weather, UV rays, and ice over many years.
Food & Pharmaceutical Processing
Securing washdown hoses and sanitary systems that undergo frequent cleaning with harsh chemical sanitizers.
How to use 316 Stainless Steel Clip
Wrap & Loop
- Feed the stainless steel band through the buckle (single or double wrap).
- Wrap it around the object, pass the tail back through the buckle, and bend the tail underneath to prevent slipping.
Load Tool
- Lift the tool's gripper lever.
- Insert the band tail through the nose slot and feed it into the gripper as far as it goes.
- Position the buckle firmly against the front nose of the tool.
Apply Tension
- Hold the band steady at the buckle.
- Turn the tension handle clockwise until the band stops sliding through the buckle. Stop turning here to avoid snapping.
Roll and Compensate
- Roll the entire tool backward (over the top of the buckle).
- Back off the tension handle counter-clockwise by about half a turn to a full turn to create slack and prevent the band from breaking.
Cut and Lock
- Pull the cutter lever up firmly to shear off the excess band tail.Hammer the "ears" of the 316 stainless steel buckle tightly down over the remaining band stub to lock it in place.
- Remove the tool.
Frequently asked questions
Here are some common questions about
316 Stainless Steel Clip
BAND-IT® Clips are used with stainless steel banding to create secure clamps for bundling, fastening, and clamping applications. They are suitable for industrial, commercial, marine, and other demanding environments.
The BAND-IT® 316 Stainless Steel Clip is manufactured from 316 stainless steel, providing excellent corrosion resistance for demanding applications.
Yes. 316 stainless steel clips are well suited to outdoor and harsh environments, including applications exposed to moisture, salt spray, UV exposure, and corrosive conditions. Arabian Arrow supplies BAND-IT® stainless steel fastening products for demanding environments across Saudi Arabia.
Yes. BAND-IT® specifically identifies its 316 stainless steel clips for general banding applications, including marine splash-zone environments.
The 316 stainless steel clip range includes 1/4", 3/8", 1/2", 5/8", and 3/4" widths, corresponding approximately to 6.4, 9.6, 12.7, 15.8, and 19.1 mm.
The standard BAND-IT® 316 stainless steel clips are supplied in boxes of 100 pieces.
Yes. The 316 stainless steel clips are designed to be used with 316 stainless steel banding, including coated and uncoated roll band
Yes. BAND-IT® states that its 316 stainless steel clip can hold either a single- or double-wrapped band configuration.
Yes. BAND-IT® band clamps can be formed over different contours and shapes, making the system suitable for a variety of clamping applications.
Stainless steel BAND-IT® fastening systems are designed for demanding industrial environments and extreme temperature conditions. The exact temperature capability should be evaluated according to the complete banding system and application
BAND-IT® offers a range of tightening and hand tools designed for installing, tensioning, and cutting stainless steel bands and fastening systems. Arabian Arrow supplies BAND-IT® installation tools in Saudi Arabia.
Arabian Arrow Supply & Services Co. Ltd. (ARACO) is an authorized distributor and stockist of BAND-IT® products in the Kingdom of Saudi Arabia
Secure Your Banding with BAND-IT® 316 Stainless Steel Clip
Choose BAND-IT® 316 Stainless Steel Clips for reliable, corrosion-resistant fastening in demanding environments.Contact us for product availability, specifications and quotations.
